Exceptional Heavy Load Performance
The BFL Series has transformed our material handling operations. The 10-foot travel distance and 4000-pound capacity perfectly meet our high mezzanine access requirements with reliable daily performance.
ANSI Compliant
UL Listed
BFL Series Hydraulic Lift Platforms
Patented Platform Centering Device
UL Listed Controllers
Machine Grade Cylinders
Price
Price Available on Request
Fast & Reliable Shipping
Custom Solutions Available
Certifications: ANSI, UL
Technical Specifications at a Glance
Detailed technical specifications for our BFL Series hydraulic lift platforms to help you make informed decisions.
Parameter
Specification
Model
BFL2-2120 / BFL2-4120
Travel Distance
10'
Load Capacity
2000 - 4000 lbs
Standard Platform
6' x 8'
Optional Maximum Platform
8' x 10'
Lowered Height
1' 3-1/2"
Raised Height
11' 3-1/2"
Motor Power
5 HP
Construction
Tubular steel legs
Country of Origin
🇺🇸
United States
Built for Performance and Reliability
Engineered with advanced features to deliver exceptional performance across demanding industrial applications.
Patented Technology
Platform Centering Device technology doubles or triples lift life, ensuring long-term reliability and reduced maintenance costs for your operations.
Safety Certified
UL listed controllers and ANSI code compliance provide industry-standard safety assurance for personnel protection and operational confidence.
Durable Construction
Machine grade cylinders with return lines and mild steel oil reservoirs ensure consistent performance and extended service life in demanding environments.
Premium Finish
Fully primed and baked enamel finish provides superior corrosion resistance and maintains professional appearance throughout years of operation.
Custom Solutions
Available with custom designs, platform sizes, and capacities to meet specific application requirements and site constraints.
Expert Support
Factory consultation services and dedicated sales and parts support ensure optimal performance and quick resolution of any issues.
Frequently Asked Questions
Can the platform size and capacity be customized?
Yes, we offer custom platform sizes beyond the standard 6' x 8' up to 8' x 10' optional maximum, as well as custom capacities and travels to meet specific application requirements and site constraints.
What safety features are included with the BFL Series?
All units include UL listed controllers, ANSI codes compliance, standard manual lowering valve, and optional two bi-parting electrically interlocked folding gates for enhanced personnel safety.
What is the typical speed and operating time for these lifts?
The BFL Series operates at 47 seconds for full travel with a 5 HP motor, providing efficient vertical transport for large loads while maintaining smooth and controlled operation.
What support services are available for the BFL Series?
We provide factory consultation for higher speeds, custom design assistance, dedicated sales support at 1-800-843-3625, and parts support through Parts@advancelifts.com for ongoing service needs.
